4-Stroke 90HP

Powerful, reliable, and built for adventure, the F85–F130 series is the ideal outboard solution for larger boats. Featuring electric start, power trim & tilt, and a remote control system, these engines deliver smooth operation, responsive handling, and outstanding performance on every trip. Whether you're fishing offshore, cruising with family, or exploring new waters, the F85–F130 series provides the confidence and power to go further.

  • Features & Benefits
  • Performance Bulletins
  • Specifications
  • Accessories
  • Related models
  • Showcases

Find a Dealer

Features & Benefits

Specification

Models
  • F90FEL-T-EFI
  • F90FEX-T-EFI
  • F90FEL-T-EFI-L
  • F90FEX-T-EFI-L
  • Max. Output Power(HP/KW)
  • Transom Height(in.)
  • Engine Type
  • Displacement(cc)
  • Bore*Stroke(mm)
  • Ignition System
  • Max. RPM Range(r/min)
  • Idling RPM Range(r/min)
  • Fuel Injection System
  • Steering System
  • Starting System
  • Gear Shift
  • Gear Ratio
  • Trim and Tilt System
  • Engine Oil Capacity(L)
  • Max. Fuel Consumption (L/H@5500rpm)
  • Engine Oil Capacity (L)
  • Gear Oil Capacity(cc)
  • Max charging（A）
  • Propeller Options(in.)
  • Weight(KG)
  • Certificate
  • 90-15.png
    • Max. Output Power(HP/KW)
      90HP(66.2kW)
    • Transom Height(in.)
      20/25
    • Engine Type
      L4DOHC
    • Displacement(cc)
      1832
    • Bore*Stroke(mm)
      81.0*88.9
    • Ignition System
      T.C.I
    • Max. RPM Range(r/min)
      5300-6300
    • Idling RPM Range(r/min)
      800-900
    • Fuel Injection System
      EFI
    • Steering System
      Remote Control
    • Starting System
      Electric
    • Gear Shift
      F-N-R
    • Gear Ratio
      2.15
    • Trim and Tilt System
      Electric
    • Engine Oil Capacity(L)
    • Max. Fuel Consumption (L/H@5500rpm)
      30.5
    • Engine Oil Capacity (L)
      3.0
    • Gear Oil Capacity(cc)
      CW：760 CCW：715
    • Max charging（A）
      12V,27A
    • Propeller Options(in.)
      3-131/4"x17" or 3-131/2"x15"
    • Weight(KG)
      181-185
    • Certificate
      CE/CCS/EPA
  • 90-15.png
    • Max. Output Power(HP/KW)
      90HP(66.2kW)
    • Transom Height(in.)
      20/25
    • Engine Type
      L4DOHC
    • Displacement(cc)
      1832
    • Bore*Stroke(mm)
      81.0*88.9
    • Ignition System
      T.C.I
    • Max. RPM Range(r/min)
      5300-6300
    • Idling RPM Range(r/min)
      800-900
    • Fuel Injection System
      EFI
    • Steering System
      Remote Control
    • Starting System
      Electric
    • Gear Shift
      F-N-R
    • Gear Ratio
      2.15
    • Trim and Tilt System
      Electric
    • Engine Oil Capacity(L)
    • Max. Fuel Consumption (L/H@5500rpm)
      30.5
    • Engine Oil Capacity (L)
      3.0
    • Gear Oil Capacity(cc)
      CW：760 CCW：715
    • Max charging（A）
      12V,27A
    • Propeller Options(in.)
      3-131/4"x17" or 3-131/2"x15"
    • Weight(KG)
      181-185
    • Certificate
      CE/CCS/EPA
  • 90-15.png
    • Max. Output Power(HP/KW)
      90HP(66.2kW)
    • Transom Height(in.)
      20/25
    • Engine Type
      L4DOHC
    • Displacement(cc)
      1832
    • Bore*Stroke(mm)
      81.0*88.9
    • Ignition System
      T.C.I
    • Max. RPM Range(r/min)
      5300-6300
    • Idling RPM Range(r/min)
      800-900
    • Fuel Injection System
      EFI
    • Steering System
      Remote Control
    • Starting System
      Electric
    • Gear Shift
      F-N-R
    • Gear Ratio
      2.15
    • Trim and Tilt System
      Electric
    • Engine Oil Capacity(L)
    • Max. Fuel Consumption (L/H@5500rpm)
      30.5
    • Engine Oil Capacity (L)
      3.0
    • Gear Oil Capacity(cc)
      CW：760 CCW：715
    • Max charging（A）
      12V,27A
    • Propeller Options(in.)
      3-131/4"x17" or 3-131/2"x15"
    • Weight(KG)
      181-185
    • Certificate
      CE/CCS/EPA
  • 90-15.png
    • Max. Output Power(HP/KW)
      90HP(66.2kW)
    • Transom Height(in.)
      20/25
    • Engine Type
      L4DOHC
    • Displacement(cc)
      1832
    • Bore*Stroke(mm)
      81.0*88.9
    • Ignition System
      T.C.I
    • Max. RPM Range(r/min)
      5300-6300
    • Idling RPM Range(r/min)
      800-900
    • Fuel Injection System
      EFI
    • Steering System
      Remote Control
    • Starting System
      Electric
    • Gear Shift
      F-N-R
    • Gear Ratio
      2.15
    • Trim and Tilt System
      Electric
    • Engine Oil Capacity(L)
    • Max. Fuel Consumption (L/H@5500rpm)
      30.5
    • Engine Oil Capacity (L)
      3.0
    • Gear Oil Capacity(cc)
      CW：760 CCW：715
    • Max charging（A）
      12V,27A
    • Propeller Options(in.)
      3-131/4"x17" or 3-131/2"x15"
    • Weight(KG)
      181-185
    • Certificate
      CE/CCS/EPA

Explore All

Accessories

Expand More

Related models


Showcase

Turkey
Showcase China
Showcase China

Want to Learn More
Click Here to Know b2_cta_parsun_logo1.svg

Boat Information

BOAT NAME
Boat Length Boat Length
Width Boat Length
Boat Net weight Boat Length
Maximum Fuel Capacity Boat Length
Test Weight Boat Length
Diesel 200
Maximum Output Power Boat Length
Engine Type Boat Length
Displacement Boat Length
Net Weight Boat Length
Gear Ratio Boat Length
Outboard Motor Mounting Position
Mounting Hole Position Boat Length
Mounting Hole Position
Series Boat Length
Diameter × Pitch Boat Length
Material Boat Length
Test Conditions
Number of Persons Boat Length
Air / Water Temperature Boat Length
Sea Level Boat Length
Wind Speed Boat Length

Engine RPM vs Speed & Fuel Consumption

Engine Speed (RPM) Boat Speed (km/h) Fuel Consumption (L/h) Fuel Efficiency (km/L)
2000 12 10 10
2500 15 17 17
3000 22 23 23
3500 28 34 34
3700 30 40 40
4000 31.5 40.8 40.8
